Manual for Drulov Model 70 & Toz 49 Revolver TargetShooting Canada Manual for Drulov Model 70 & Toz 49 Revolver Posted by (203.26.188.65) on October 09, 2006 at 04:03:13: I am looking for copies of the owners manual for the following target pistols, Drulov Mod 70 & Toz 49 revolver. Enter your Model Number (E-Nr) below. If you already know your Model Number, just enter the first few characters. If you don’t know it, please find it on the Rating Plate, then simply click on the camera icon to take a photo or upload a photo of the Rating Plate – this will automatically add the Model Number for you. Single shot made for accuracy with a barrel of nearly 10' and with an excellent sight picture. Set button/trigger, and a thumb rest on an extremely comfortable grip in great condition which is a delight to hold & has not been altered in any way. The whole gun is in very good condition for its age, a very good find for a Mod 70, bore is clean & shiny, gun has been cleaned & handled with great. Drulov DU 10 Pistol OWNER'S MANUAL. Sight Adjustment. The rear sight leaf may be laterally or vertically adjusted by turning the serrated screw hands (6 and 7) located on the right and left hand sife of the rear sight assembly. The letters engraved on top of the assembly indicate the direction of adjustment. Drulov DU 10 Pistol OWNER'S MANUAL. TECHNICAL DATA; Mechanical system: Five shot CO2 powered repeater Caliber/Ammunition: BB cal (4.5mm).177 cal (4.5mm) Magazine capacity: Up to five pellets or BB's in semi-automatic mode without reloading Total length: 30 cm Weight: 1.5 kg.

MainOperatingLoading/FiringAdjustmentsSafety

  • The rear sight leaf may be laterally or vertically adjusted by turning the serrated screw hands (6 and 7) located on the right and left hand sife of the rear sight assembly.
  • The letters engraved on top of the assembly indicate the direction of adjustment. Turning the screw head by one click shifts the point of impact by 3mm at 10 meters.
Muzzle Velocity
  • The velocity may be adjusted from 262fps to 410 fps. by turning the slotted nut (3) which is located below the muzzle.
  • Turn the nut clockwise to increase the muzzle velocity, counter-clockwise to reduce.
  • A 12g CO2 bulb should contain enough propellant gas for about 70 discharges if the muzzle velocity is set at the optimum level of 311-377 fps.
Trigger Position
Drulov Model 70 Manual
  • The trigger is fitted on to the devetailed trigger bar. The trigger position may be adjusted whithin a range of 8mm by releasing the screw (12) and shifting the trigger into a convenient position. Be sure to tighten the screw again.
Trigger Pull Weight
  • The screw located in front of the trigger guard serves to adjust the trigger pull from 3N to 7N. Turn it clockwise to increase, the reverse to decrease. Never apply force when making adjustments. If you try to set the trigger pull too low, the trigger will frequently remain stuck in the rear most position after discharge. In this case, turn the screw (9) clockwise until reliable functioning is restored.
Trigger Stop and Trigger Pull Length
  • The trigger stop and trigger pull are controlled by the two screws (10 and 11) located behind the trigger.
  • First, turn the pistol upside down. Turn screw 11, the trigger stop screw, clockwise to reduce the play after discharde and the reverse to increse the play.
  • Turn the trigger pull length adjustment screw, screw 10, clockwise to reduce, the reverse to increase.
  • An audible click indicates the trigger has engaged the matching part of the trigger assembly. After that, it is recommended the screw is turned another 90 degrees to achieve both shortest trigger pull length as well as reliable operation of the trigger.
